DEUBLIN 1102-070-081 (102-070-081)
The Deublin 1102-070-081 is a precision-engineered Monoflow Rotary Union designed for reliable fluid transfer in demanding industrial applications.
Technical Specifications:
-
Type: Monoflow
-
Rotor Connection: 1/4″ NPT Right Hand (RH)
-
Housing Connection: 1/4″ NPT
-
Media Compatibility: Air, Hydraulic Oil
-
Max Hydraulic Pressure: 103 bar (1,500 PSI)
-
Max Temperature: 121°C (250°F)
-
Housing Material: Anodized Aluminum
Reliable Fluid Transfer with the Deublin 1102-070-081 Monoflow Union
The Deublin 1102-070-081 (102-070-081) is a high-performance Monoflow Rotary Union engineered for precision fluid and air transfer in compact industrial environments. Designed with a robust anodized aluminum housing and a hardened steel rotor, this 1/4" NPT (Right Hand) unit is built to withstand the demanding conditions of New Zealand's forestry and manufacturing sectors.
Whether you are managing air lines or hydraulic oil systems, the 1102 series provides a leak-proof connection even at pressures up to 103 bar (1,500 PSI) and temperatures reaching 121°C. Its compact footprint makes it the "go-to" choice for smaller hydraulic actuators where space is limited but reliability is non-negotiable.
By choosing the Deublin 1102-070-081, you are investing in a component known for its longevity and resistance to the grit and debris often found on active worksites. Ensure your machinery maintains peak efficiency with this industry-standard rotary union.
Product Applications
Commonly used in forestry equipment and industrial machinery for high-precision fluid transfer, the Deublin 1102 series is ideal for small-scale hydraulic actuators. Its anodized aluminum body provides superior corrosion resistance in harsh outdoor environments, making it a favorite for New Zealand's forestry conditions
